2002-2009 Chevy Trailblazer / GMC Envoy 12" Sub Box Package with Harmony HA-R124 12" Sub, Kicker CX300.1 / CXA4001 600W Amp & HA-AK10 Kit

Package Includes: 1 x GMC Envoy 02-09 12" Sub Box Enclosure; 1 x Harmony Audio HA-R124 Rhythm Series 12" Single 4 Ohm Sub (600W peak / 300W RMS); 1 x Kicker CX300.1 Car Audio CX Series Class D Subwoofer Amplifier (600W max); 1 x Harmony Audio HA-AK10 10 Gauge 600 Watt Amp Kit - Nickel Finish. Enclosure (fits Chevy Trailblazer / GMC Envoy 02-09): Sealed 12" subwoofer box designed to mount on the passenger sidewall of the rear cargo area. Air Space: 0.80 Cubic Feet. Mounting Depth: 6-1/4". Sealed enclosure overall dimensions: Bottom Width 24-1/4" x Top Width 11" x Height 13-1/2" x Depth 6-5/8". Harmony Audio HA-R124 12" Subwoofer: Rhythm Series single 12" driver, single 4 ohm voice coil. Power handling: Peak 600 watts, RMS 300 watts. Sensitivity: 88.2dB. Frequency response: 27Hz-1.8kHz. Mounting depth: 5 11/16". Mounting cutout diameter: 11 1/8". Kicker CX300.1 Subwoofer Amplifier (Class D) - 600 Watt capability: RMS power rating: 4 ohms: 150 watts x 1 chan.; 2 ohms: 300 watts x 1 chan.; maximum power output: 600 watts x 1 chan. Features include variable bass boost (0 to +12 dB at 40 Hz), variable low-pass filter (50-200 Hz, 12 dB/octave), subsonic filter (24 dB at 25 Hz) and frequency response of 25-200 Hz. Installation Kit: Harmony Audio HA-AK10 10 Gauge amp kit, rated for 600 Watt systems, nickel finish hardware included. This package supplies the enclosure, driver, amplification, and wiring components needed for a complete single 12" sub install in 2002-2009 Chevy Trailblazer / GMC Envoy vehicles.
