FAITAL PRO 6" Midrange Driver 120W AES — 8 Ohm (6PR122-8)

Overview: The FAITAL PRO 6PR122-8 is a 6" midrange driver designed for high-efficiency vocal and instrument reproduction. It features a neodymium ring motor, aluminum demodulation ring and an aluminum basket for lightweight rigidity. Rated AES power is 120 W with a maximum power rating of 240 W, and it delivers 97 dB sensitivity (1W/1m). Mechanical & mounting dimensions: - Nominal Diameter: 160 mm (6 in) - Overall Diameter: 186.5/162 mm (7.34/6.37 in) - Bolt Circle Diameter: 172 mm (6.77 in) - Baffle Cutout Diameter: 147 mm (5.79 in) - Depth: 78 mm (3.07 in) - Flange and Gasket Thickness: 9.5 mm (0.37 in) - Net Weight: 1.3 kg (2.8 lb) - Shipping Box (Single Carton Box): 190 x 185 x 103 mm (7.5 x 7.3 x 4.1 in) - Shipping Weight: 1.5 kg (3.2 lb) Electrical & power handling: - Nominal Impedance: 8 Ohm - Minimum Impedance: 6.8 Ohm - AES Power Handling (1): 120 W - Maximum Power Handling (2): 240 W - Sensitivity (1W/1m): 97 dB - Frequency Range: 12510000 Hz Voice coil and motor assembly: - Voice Coil Diameter: 37 mm (1.46 in) - Winding Material: Al - Former Material: Kapton - Winding Depth: 7.5 mm (0.30 in) - Magnetic Gap Depth: 6 mm (0.24 in) - Flux Density: 1.6 T - Magnet: Neodymium Ring - Demodulation: Aluminum Ring - Basket Material: Aluminum Suspension, acoustic volume & spider: - Cone Surround (3): Half Roll - NET Air Volume filled by Loudspeaker: 0.38 dm^3 (0.013 ft^3) - Spider Profile: 1x constant height waves Thiele & Small parameters: - Fs: 110 Hz - Re: 6 Ohm - Qes: 0.44 - Qms: 3.3 - Qts: 0.39 - Vas: 4.7 dm^3 (0.17 ft^3) - Sd: 137.3 cm^2 (21.28 in^2) - Xmax (4): 2.75 mm - Xdamage (5): 11.6 mm - Mms: 11.7 g - Bl: 10.5 N/A - Le: 0.15 mH - Mmd: 9.9 g - Cms: 0.18 mm/N - Rms: 2.4 kg/s - Eta Zero: 1.38 % - EBP: 250 Hz Identification & part info: - Brand: FAITAL PRO - Model Number: 6PR122-8 6PR122 - UPC: 810130951376 - PART NUMBER (P/N) Faston Terminals - 8 Ohm Version: 01604160 Notes: (1) 2 Hours Test According to AES 2-1984 Rev. 2003 (2) Maximum power is defined as 3dB greater than nominal power (3) Treated Polycotton (4) Xmax= [(winding depth - magnetic gap depth)/2] + (magnetic gap depth/3) (5) Maximum excursion before permanent damage
