Load Cell Electronic Weighing Scale 100kg200kg 500kg Pressure Sensor Module PLC Communication

Rated load 50, 60, 100, 150, 200, 250, 300, 500, 600, 750, 800, 1000, 1200 (kg) output temperature effect 0.002%R0./C Zero temperature effect 0.003%R0./C Zero balance ±0.0200 mV/V input resistance 390±15 2; 410±15 Q output impedance 350±5 Q Insulation resistance 25000 MS / (50VDC) Safe overload rate 150%R. 0. Limit overload rate 200%R 0. range of working temperature -20^60C Recommended working voltage 5 12VDC Maximum working voltage 15VDC material aluminum alloy; steel alloy cable φ5X2 m Wiring Red: Power+, Black: Power-, Green: Signal+, White: 枵-
